Liberica Native Image Kit 22.2.0 and 21.3.3 builds are out

figure
Aug 5, 2022
Peter Zhelezniakov

We are happy to announce the general availability of Liberica Native Image Kit (NIK) versions 22.2.0 and 21.3.3 as part of Critical Patch Update (CPU) release cycle. The builds contain several security fixes and enhancements.

Liberica Native Image Kit is a GraalVM-based tool that helps to convert JVM-based applications into native executables and thus minimizes resource consumption and accelerates the startup time of applications. Liberica NIK supports multiple system configurations and languages and is part of a Cloud Native Buildpack together with Spring, which enables seamless generation of native images with Spring Boot.

All Liberica NIK builds contain the latest version of Liberica JDK with fixes and eliminated security issues.

  1. Summary of fixes and enhancements
    1. List of security issues fixed
    2. Summary of fixes in Liberica NIK
  2. Enhanced AWT/Swing support
    1. Set up your workspace
    2. Generate configuration files
    3. Create a native image for SwingSet2 app (Linux and macOS)
    4. Create a native image for SwingSet2 app (Windows)
  3. Conclusion

Summary of fixes and enhancements

List of security issues fixed

CVE IDcvss scorecomponentmoduleAttack vector (network/local)Complexity (low/high)Privileges (none/low)User interaction (none/required)Scope (changed/unchanged)Confidentiality (low/none/high)Integrity (low/none/high)Availability (low/none/high)
CVE-2022-341697.5xmljava.xmlnetworklownonenoneunchangednonehighnone
CVE-2022-215405.3core-libsjava.basenetworklownonenoneunchangedlownonenone
CVE-2022-215415.9core-libsjava.basenetworkhighnonenoneunchangednonehighnone
CVE-2022-215495.3core-libsjava.basenetworklownonenoneunchangednonelownone

Summary of fixes in Liberica NIK

CVEs fixed in Liberica NIK per version:

CVECVSS21.3.3 (JDK 11)21.3.3 (JDK 17)22.2.0 (JDK 11)22.2.0 (JDK 17)
CVE-2022-341697.5
CVE-2022-215405.3
CVE-2022-215415.9
CVE-2022-215495.3--

Enhanced AWT/Swing support

In the previous Liberica NIK release, we added support for AWT/Swing for Linux. Now we extend the support to Windows and macOS. In the case of GraalVM with JDK 11 or 17 on Windows, an application will be converted into a native executable plus dynamic libraries necessary for AWT/Swing and taken from the JDK. As far as macOS is concerned, an app will be transformed into a single native executable.

Below you will find the detailed instructions on how to create native images of a SwingSet2 demo app using Liberica NIK for three platforms — Linux, macOS, and Windows.

Set up your workspace

First, download Liberica Native Image Kit for your platform. Refer to the Install Guide for installation instructions. Set the PATH variable to Liberica NIK:

PATH=<path-to-nik>/bin:$PATH

Download JDK 8 demos with SwingSet2. You will find the app in the demo/jfc/SwingSet2 folder upon archive extraction.

Generate configuration files

The next step is to create configuration files specific to the SwingSet2 demo using a native image agent.

  1. Run java from Native Image Kit with “-agentlib:native-image-agent=config-output-dir=conf-dir” parameters

     java -agentlib:native-image-agent=config-output-dir=conf-dir -jar SwingSet2.jar


  2. Click on several demo tabs and select several Look & Feels from “Look & Feel” menu
  3. Close the SwingSet2 demo

    The directory conf-dir contains configuration files in JSON format.

    • The reflect-config.json file describes classes that will be accessed reflectively from the demo. It includes both the reflection classes related to the SwingSet2 demo and to JDK classes. Edit the reflect-config.json file to leave only the description for SwingSet2 demo classes accessed by reflection. You need to leave only the reflections related to the SwingSet2 demo. Below you will find the adjusted reflect-config.json file.

[

{

  "name":"ButtonDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"ColorChooserDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"ComboBoxDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"FileChooserDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"HtmlDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"ListDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"OptionPaneDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"ProgressBarDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"ScrollPaneDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"SliderDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"SplitPaneDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"TabbedPaneDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"TableDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"ToolTipDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

},

{

  "name":"TreeDemo",

  "methods":[{"name":"<init>","parameterTypes":["SwingSet2"] }]

}

]

  • The resource-config.json file defines resources that should be accessible at image run time. It includes both resources related to SwingSet2 demo and for Swing Look&Feels. Edit the resource-config.json file to leave only the resources related to the SwingSet2 demo. Find the adjusted resource-config.json file below.

{

  "resources":{

  "includes":[

    {

      "pattern":"\\QButtonDemo.java\\E"

    },

    {

      "pattern":"\\QColorChooserDemo.java\\E"

    },

    {

      "pattern":"\\QComboBoxDemo.java\\E"

    },

    {

      "pattern":"\\QFileChooserDemo.java\\E"

    },

    {

      "pattern":"\\QHtmlDemo.java\\E"

    },

    {

      "pattern":"\\QInternalFrameDemo.java\\E"

    },

    {

      "pattern":"\\QListDemo.java\\E"

    },

    {

      "pattern":"\\QOptionPaneDemo.java\\E"

    },

    {

      "pattern":"\\QProgressBarDemo.java\\E"

    },

    {

      "pattern":"\\QScrollPaneDemo.java\\E"

    },

    {

      "pattern":"\\QSliderDemo.java\\E"

    },

    {

      "pattern":"\\QSplitPaneDemo.java\\E"

    },

    {

      "pattern":"\\QTabbedPaneDemo.java\\E"

    },

    {

      "pattern":"\\QTableDemo.java\\E"

    },

    {

      "pattern":"\\QToolTipDemo.java\\E"

    },

    {

      "pattern":"\\QTreeDemo.java\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/apple.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/asparagus.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/banana.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/broccoli.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/cantaloupe.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/carrot.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/corn.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/grapefruit.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/grapes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/kiwi.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/onion.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/peach.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/pear.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/pepper.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/pickle.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/pineapple.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/raspberry.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/strawberry.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/tomato.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/food/watermelon.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/misc/cab.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/misc/cab_small.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/misc/fish.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/misc/fish_small.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/misc/moon.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/misc/moon_small.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/misc/sun.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/ImageClub/misc/sun_small.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b1.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b1d.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b1p.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b1r.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b2.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b2d.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b2p.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b2r.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b3.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b3d.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b3p.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/b3r.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/bl.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/bldn.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/bm.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/bmdn.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/br.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/brdn.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/c.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/cb.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/cbr.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/cbrs.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/cbs.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/cdn.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/ml.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/mldn.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/mr.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/mrdn.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/rb.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/rbp.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/rbr.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/rbrs.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/rbs.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/tl.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/tldn.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/tm.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/tmdn.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/tr.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/buttons/trdn.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/brenteyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/brenthair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/brentmouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/georgeseyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/georgeshair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/georgesmouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/hanseyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/hanshair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/hansmouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/howardeyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/howardhair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/howardmouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/jameseyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/jameshair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/jamesmouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/jeffeyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/jeffhair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/jeffmouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/joneyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/jonhair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/jonmouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/laraeyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/larahair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/laramouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/larryeyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/larryhair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/larrymouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/lisaeyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/lisahair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/lisamouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/michaeleyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/michaelhair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/michaelmouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/philipeyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/philiphair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/philipmouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/scotteyes.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/scotthair.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/combobox/scottmouth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/filechooser/find.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/filechooser/gifIcon.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/filechooser/help.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/filechooser/jpgIcon.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/list/blue.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/list/cyan.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/list/gray.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/list/green.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/list/magenta.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/list/red.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/list/yellow.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/optionpane/bottle.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/scrollpane/colheader.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/scrollpane/crayons.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/scrollpane/lowerleft.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/scrollpane/rowheader.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/scrollpane/upperleft.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/scrollpane/upperright.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/splitpane/earth.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/splitpane/moon.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/tabbedpane/blake.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/tabbedpane/brooke.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/tabbedpane/david.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/tabbedpane/ewan.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/tabbedpane/ewan.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/tabbedpane/hania.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/tabbedpane/laine.jpg\\E"

    },

    {

      "pattern":"\\Qresources/images/tabbedpane/matthew.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/tabbedpane/stephen.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JButton.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JColorChooser.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JComboBox.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JDesktop.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JEditorPane.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JFileChooser.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JList.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JOptionPane.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JProgressBar.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JScrollPane.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JSlider.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JSplitPane.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JTabbedPane.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JTable.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/JTree.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/toolbar/ToolTip.gif\\E"

    },

    {

      "pattern":"\\Qresources/images/tooltip/cow.gif\\E"

    },

    {

      "pattern":"\\Qresources/index.html\\E"

    },

    {

      "pattern":"\\Qresources/swingset.properties\\E"

    },

    {

      "pattern":"\\Qresources/tree.txt\\E"

    }

  ]},

  "bundles":[

    {

      "name":"resources.swingset"

    }

  ]

}

  1. Set java.awt.headless Java property explicitly to false:

     -Djava.awt.headless=false



Create a native image for SwingSet2 app (Linux and macOS)

To build the native image, you need to provide the resource and reflection files apart from stating the java.awt.headless property. Run the following command

native-image -Djava.awt.headless=false -H:ReflectionConfigurationFiles=conf-dir/reflect-config.json -H:ResourceConfigurationFiles=conf-dir/resource-config.json -jar SwingSet2.jar

Metal Look&Feel (Linux)

A note for macOS users — to run the application, go to the app directory and use the following command:

./SwingSet2

Aqua Look&Feel (macOS)

Create a native image for SwingSet2 app (Windows)

You need to have Microsoft Visual Studio installed to create a native image.

To set the environment required for Microsoft Visual Studio, run the vcvars64.bat file:

C:\Program Files (x86)\Microsoft Visual Studio\2019\Community\VC\Auxiliary\Build\vcvars64.bat

After that, provide the resource and reflection files. To enable HiDPI support, provide the manifest file “SwingSet2.exe.manifest”, where

  • dpi1:dpiAware is set to true/PM
  • dpi2:dpiAwareness is set to PerMonitorV2, PerMonitor, system

Finally, the command for generating a native image is as follows:

native-image.cmd  -Djava.awt.headless=false -H:ReflectionConfigurationFiles=conf-dir/reflect-config.json -H:ResourceConfigurationFiles=conf-dir/resource-config.json -jar SwingSet2.jar

As a result, the SwingSet2.exe and SwingSet2.exe.manifest will be produced.

Windows Look&Feel (Windows)

Conclusion

BellSoft strives to provide Java developers with a full stack of secure and affordable technologies suitable for creating a wide range of applications. Not only does Liberica Native Image Kit enable you to create performant microcontainers with minimal startup time, it enhances the experience of working with Swing and AWT apps. Download the latest version of Liberica NIK now!

posts
Alpaquita vs Alpine: a head-to-head comparison
figure
Nov 10, 2022
Dmitry Chuyko
shorts
Critical vulnerabilities in OpenSSL 3.0
Nov 11, 2022
Sergey Chernyshev

Find out about the newest CVEs discovered in OpenSSL 3.0 and how to eliminate the risk of exploits

Subcribe to our newsletter

figure

Read the industry news, receive solutions to your problems, and find the ways to save money.
